1. Bench pickup check
Start with representative parts, including the worst expected surface condition. Check pickup contact, peel risk, air gap, and any stacked-part behavior before approving the gripper concept.
← Back to Solutions
Robot Pick-and-Place
Magnetic gripping for robot transfer of steel parts where contact pickup can simplify tooling.
Target Buyer:For robot integrators comparing magnetic gripping with vacuum, clamp, or mechanical finger tools.
Solution Highlights
- Robot payload and motion review
- Workpiece center-of-gravity checks
- Custom mounting and cable routing
Common Use Cases
- Robot transfer
- Fixture loading
- Line feeding
Implementation Focus
- Payload, moment, and acceleration
- Pickup orientation and dynamic forces
- Release verification and placement repeatability
Robot Pick-and-Place Buyer Decision Framework
Treat robot pick-and-place as a complete handling decision, not a stand-alone magnet purchase. The right choice depends on whether the workpiece can be held magnetically, whether the robot motion keeps enough margin, whether the part releases cleanly, and whether the installation scope is clear enough for quotation.
Buyer fit: For robot integrators comparing magnetic gripping with vacuum, clamp, or mechanical finger tools. Before comparing price, align the practical constraints below so the quote reflects the real automation cell instead of a generic catalog condition.
| Decision Area | Buyer Question | Practical Evidence |
|---|---|---|
| Workpiece fit | Can the magnetic poles contact enough real surface area under production conditions? | Send part material, weight, pickup face geometry, and surface condition plus photos or drawings of the pickup face. |
| Motion margin | Will the gripper hold through acceleration, rotation, off center pickup, and stop conditions? | Review dynamic grip requirement because a static pickup test alone does not prove the cell can run at production motion. |
| Release behavior | Can the part release within the placement tolerance without residual magnetism, double pickup, or stack disturbance? | Define sample acceptance criteria around dynamic grip requirement and record the release test result before batch release. |
| Interface scope | Are the flange, adapter, cable, connector, controller, and documentation assumptions included in the same RFQ? | Confirm payload, moment, and acceleration and list any custom mounting or control requirements before PO release. |
Validation Plan Before application validation
2. Robot-path check
Test the planned orientation, acceleration, tool center, cable route, and stop assumptions. A static lift is not enough when the cell includes fast motion or rotated handling.
3. Release and repeat run
Measure release timing, residual magnetism, placement tolerance, and repeatability across a small run. Use the result to freeze pole layout, interface, and quality-control notes.
Procurement Notes and Boundaries
The most common sourcing mistake is treating holding force as a fixed catalog value. In practice, gripper passes static pickup test but drops the part during high-acceleration transfer. Test at production speed with realistic acceleration, rotation, and emergency-stop conditions, not only slow manual jog. Another common issue is that placement accuracy degrades because the part shifts on the magnetic face during motion. Add mechanical locating features or verify that the magnetic holding force prevents lateral sliding under the worst-case acceleration vector.
For a quote that can move from engineering review to procurement, include the workpiece file set, automation interface, cycle target, release requirement, quantity, destination, and any custom packaging or documentation needs. If those values are not final, mark them as assumptions so the quotation can separate confirmed scope from validation-dependent scope.
- Use Contact / RFQ when drawings, photos, robot model, and quantity are ready for review.
- Review sample validation and quality control if the application includes coating, oil, burrs, stack variation, or release precision risk.
Application Evaluation Matrix
| Evaluation Metric | Typical Range | Buyer Relevance |
|---|---|---|
| Dynamic grip requirement | Estimated from motion profile and validated with samples | A static pickup test alone does not prove the cell can run at production motion. |
RFQ Preparation Checklist
- Part material, weight, pickup face geometry, and surface condition
- Robot model, reach, payload, and available motion path data
- Pick station and place station layout, clearance, and fixture design
- Cycle time target, acceleration limits, and orientation changes during transfer
- Production volume, shift pattern, and changeover frequency between part types
Risk and Mitigation
- Gripper passes static pickup test but drops the part during high-acceleration transfer.: Test at production speed with realistic acceleration, rotation, and emergency-stop conditions, not only slow manual jog.
- Placement accuracy degrades because the part shifts on the magnetic face during motion.: Add mechanical locating features or verify that the magnetic holding force prevents lateral sliding under the worst-case acceleration vector.
- Pick-and-place cycle time cannot be met because release or confirmation takes too long.: Include release time and confirmation sensor delay in the cycle time budget from the concept phase, not as a commissioning discovery.
